🚀 Upgrade to 100G Without Changing Fiber | Cisco QSFP-40/100G-SRBD=

Dual-Rate 40G/100G BiDi Solution Over Existing LC Fiber

The Cisco QSFP-40/100G-SRBD= is an advanced dual-rate 40G/100G BiDi QSFP28 optical transceiver designed to deliver high-speed connectivity over duplex multimode fiber (LC).

Unlike traditional SR4 modules that require MPO cabling, this BiDi module enables 40G or 100G transmission over existing LC fiber infrastructure, making it the ideal solution for cost-efficient network upgrades.

Built by Cisco Systems, it ensures reliable performance and seamless integration in modern data center environments.

🔥 Why This Product Converts Extremely Well

✔ Want to upgrade from 10G / 40G → 100G? ✔ Don’t want to replace existing LC cabling? ✔ Need a fast, low-cost migration path?

👉 This module solves the biggest barrier to 100G: cabling cost

⚡ SR4 vs BiDi (Critical Buying Decision)

Feature	SR4 (Traditional)	SRBD (BiDi)
Fiber	MPO (8/12-core)	LC Duplex (2-core)
Cabling Cost	High	Low
Deployment	Complex	Simple
Upgrade Scenario	New DC build	Existing DC upgrade

👉 If your customer already uses LC → SRBD is the best choice

🧠 Key Features of Cisco QSFP-40/100G-SRBD=

Dual Data Rate: 40G / 100G

Technology: Bi-directional (BiDi)

Wavelength: 850nm / 910nm

Distance:

70 m (OM3)

100 m (OM4)

Connector: LC Duplex

Fiber Type: Multimode fiber (MMF)

Form Factor: QSFP28

Digital Optical Monitoring (DOM): Supported

Hot-swappable

Designed for Cisco platforms

🏗️ High-Conversion Application Scenarios

1. 40G → 100G Data Center Upgrade

No fiber replacement required

Fast migration

2. Brownfield Data Center Optimization

Reuse existing LC infrastructure

Reduce downtime

3. Enterprise Network Expansion

Increase bandwidth without major investment

4. Cloud & Hyperscale Environments

High-density deployment

Flexible upgrade paths

💰 Biggest Advantage: Reduce Upgrade Cost

👉 Traditional 100G deployment requires:

MPO cabling

New patch panels

Infrastructure redesign

👉 With QSFP-40/100G-SRBD=:

Use existing LC fiber

Minimal changes

Faster ROI

✅ Save up to 50% on cabling and deployment costs

🧩 Complete 100G Upgrade Solution

✅ Optical Modules

Cisco QSFP-40/100G-SRBD=

Cisco QSFP-100G-SR4 (for MPO deployments)

✅ Cabling

Existing LC multimode fiber (OM3 / OM4)

✅ Equipment

40G / 100G switches

Hybrid network environments

👉 Perfect for phased upgrades

📊 Technical Specifications

Parameter	Specification
Form Factor	QSFP28
Data Rate	40 / 100 Gbps
Standard	40G/100G BiDi
Wavelength	850 / 910 nm
Max Distance	70 m (OM3) / 100 m (OM4)
Connector	LC Duplex
Fiber Type	Multimode
Tx Power	-6 ~ 4 dBm
Rx Sensitivity	≤ -8.5 dBm
Power Supply	3.3V
Operating Temp	0°C to +70°C
DOM Support	Yes
Compliance	QSFP28 MSA, RoHS

❓ FAQ

Q1: Can I upgrade to 100G without changing fiber?

Yes, this BiDi module allows 100G transmission over existing LC fiber.

Q2: Does it support both 40G and 100G?

Yes, it is a dual-rate module supporting both speeds.

Q3: Do I need MPO cables?

No, it works with standard LC duplex fiber.

Q4: What is the maximum transmission distance?

Up to 100 meters over OM4 multimode fiber.

📈

Cisco QSFP-40/100G-SRBD, QSFP-40/100G-SRBD=, Cisco 100G BiDi module, 40G to 100G upgrade module, 100G LC transceiver, BiDi QSFP28, Cisco data center upgrade solution, 100G without MPO

🚀 Get a Quote — Upgrade to 100G Without Re-Cabling

👉 Planning a 100G upgrade?

✔ No fiber replacement

✔ Faster deployment

✔ Lower total cost

Contact us now for pricing and availability.

Cisco QSFP-40/100G-SRBD= Dual-rate 40G/100G BiDi QSFP28 optical transceiver
