Cisco QDD-800G-VR8 Compatible QSFP-DD Transceiver
QDD-800G-VR8 Compatible, Cisco compatible optical module, 800GBASE-VR8 QSFP-DD for Cisco, 850nm 50m transceiver, Cisco Nexus 9000 QSFP-DD800 module, QSFP-DD 800G multimode transceiver
Cisco QDD-800G-VR8 Compatible QSFP-DD Transceiver
800GBASE-VR8 QSFP-DD Transceiver Module | Dual MPO-12 MMF | 50m DOM Support
Product Overview
The Cisco QDD-800G-VR8 Compatible QSFP-DD Transceiver is a high-performance 800GBASE-VR8 module for short-reach 800G Ethernet. Using parallel optics over multimode fiber at 850nm, it delivers 800Gbps through dual MPO-12 connectors for Cisco Nexus 9000 QSFP-DD800 platforms.
Key Features
- Supports 800GBASE-VR8 Ethernet
- QSFP-DD hot-pluggable form factor
- Dual MPO-12 optical connectors
- Parallel 8-channel optical transmission
- Up to 50m over OM4 MMF
- Integrated Digital Optical Monitoring (DOM)
- Low power consumption under 15W
- Fully compliant with IEEE 802.3ck and QSFP-DD MSA
Technical Specifications
Parameter | Specification |
Model | QDD-800G-VR8 Compatible |
Form Factor | QSFP-DD |
Data Rate | 800Gbps |
Optical Standard | 800GBASE-VR8 |
Optical Technology | Parallel Optics |
Fiber Type | Multimode Fiber (MMF) |
Wavelength | 850nm |
Max Distance | 50m (OM4) |
Connector Type | Dual MPO-12 |
DOM Support | Yes |
Power Consumption | < 15W |
Hot Swappable | Yes |
Operating Temperature | 0°C to 70°C |
Compliance | IEEE 802.3ck, QSFP-DD MSA, RoHS |
Compatibility | Cisco Nexus 9000 series switches with QSFP-DD800 ports |
Why Choose the Cisco QDD-800G-VR8 Compatible QSFP-DD Transceiver?
This compatible module delivers the same 800G VR8 performance as the original Cisco optic, at a lower cost and with full DOM visibility.
High-Value Application Scenarios
- Data center spine-leaf 800G interconnects
- High-density server and storage connectivity
- Short-reach 800G links within a data hall
- AI and high-performance computing clusters
Compatibility
This module is designed for Cisco Nexus 9000 QSFP-DD800 platforms, including Cisco Nexus 9000 series switches with QSFP-DD800 ports.
FAQ
Is this module compatible with Cisco Nexus 9000 switches?
Yes. It is designed for Cisco Nexus 9000 series switches with QSFP-DD800 ports and is tested for reliable operation in Cisco environments.
What fiber and distance does this module support?
It uses multimode fiber at 850nm and supports links up to 50m over OM4 MMF through dual MPO-12 connectors.
Does this module support DOM monitoring?
Yes. Integrated Digital Optical Monitoring (DOM) lets you monitor temperature, voltage, and optical power in real time.
Get a Quote
Contact us for a quote on the Cisco QDD-800G-VR8 Compatible QSFP-DD Transceiver. Tell us your quantity and delivery requirements, and our team will respond with pricing and availability.
